JEE Advance - Physics (2016 - Paper 1 Offline - No. 18)
Explanation
The circuit is shown in the figure

Initially, right after the circuit is switched on ($ t \rightarrow 0^{+} $), the impedance (effective resistance) of inductors $ L_1 $ and $ L_2 $ is extremely high. Therefore, the inductors act as open circuits, and all the current flows through the resistor $ R = 12 \Omega $. According to Kirchhoff's law, the current through the battery at this moment is $ i_{\min} = \frac{V}{R} = \frac{5}{12} \, \text{A} $.
As the circuit reaches steady state ($ t \rightarrow \infty $), the impedance of the inductors drops to zero, and they function as resistors with their specified internal resistances.

The effective resistance of the circuit is $R_e=(12 \Omega \|$ $4 \Omega)\|3 \Omega=3 \Omega\| 3 \Omega=3 / 2 \Omega$.
In the steady state, the current through the circuit is $ i_{\max} = \frac{V}{R_e} = \frac{5}{\frac{3}{2}} = \frac{10}{3} \, \text{A} $.
Therefore, the ratio of the maximum current to the minimum current is:
$ \frac{i_{\max}}{i_{\min}} = \frac{\frac{10}{3}}{\frac{5}{12}} = \frac{10}{3} \times \frac{12}{5} = 8 $
